Thatcham, UK – 11 April 2022: PHABRIX a broadcast test & measurement innovator, is pleased to announce the inclusion of a new Dolby E decoding and metadata analysis option in the latest release (V4.6) for its Qx and QxL Series rasterizers. The latest addition to these advanced rasterizer ranges, the PHQXO-DOLBY option, allows users to decode a Dolby E or ED2 Dolby Atmos audio stream routinely used in Live Broadcast applications and obtain a clear view of Dolby E metadata.
The new update heralds a host of additional benefits to customers working with Dolby E or ED2 audio streams. Chief amongst these is a Dolby E decoder and metadata analyzer that allows users to check the correct timing of Dolby E packets in the audio signal of an SDI or ST 2022-6 broadcast chain. Providing a clear and accessible view of Dolby E metadata, the option also makes it possible to monitor Dolby audio from any of the SDI/2022-6 embedded audio, 2110-30 / -31 audio flows or AES inputs.
PHQXO-DOLBY also enables metering and monitoring of the decoded audio, along with the ability to separately measure the loudness of a 5.1 or stereo 2.0 decoded program. A new ‘Dolby view mode’ is provided for the Audio Meter window which displays the eight channels of decoded Dolby E audio together with a configurable stereo 2.0 downmix, whilst the Dolby program metadata facilitates automatic identification and configuration of the meter channels. A status display of parameters presents Dolby E source, line positioning, dialogue level and downmix program source. Decoded audio may be routed to the AES Outputs for external monitoring.
In addition, users can take advantage of built-in Cyclic Redundancy Check (CRC) error reporting, which affords a real-time check on the creation and transfer of the Dolby E stream through the broadcast network. Moreover, for SDI and 2022-6 interfaces, a live update of Dolby E line timing is provided. Color-coding of the line number label indicates when the line number is within the ideal range (white), within the acceptable range (yellow) or outside the acceptable range (red).
Phillip Adams, CEO, PHABRIX comments: “The story of our world-renowned Qx and QxL products is one characterized by refinements and additions, and that continues with this latest release geared towards broadcasters working with Dolby E or ED2 audio streams. With the V4.6 release they now have access to a host of decoding, metering and monitoring capabilities that will ensure their Dolby audio workflows can be managed and processed more easily and efficiently.”
PHABRIX is a world leader in broadcast test and measurement, with a full range of portable and rackmount systems for rapid fault diagnosis, compliance monitoring, and product development. Technology strengths include IP video stream generation and analysis, advanced HDR/WCG visualization, and ultra-responsive physical layer analysis. The product portfolio includes the top-of-the range Qx Series for hybrid IP, 4K/UHD, and HDR/WCG signal generation, analysis, and video/audio monitoring. The advanced, rackmount Rx range provides fast intermittent fault diagnosis in 3G/HD/SD-SDI environments, using video capture and remote access. For applications demanding ultra-portable instruments, the company also offers the award-winning Sx range. PHABRIX maintains its headquarters and manufacturing facilities in the UK. PHABRIX is a member of the Leader Electronics Corporation group of companies. www.phabrix.com
