PHABRIX adds class-leading waveform monitoring instrumentation to its Qx and QxL rasterizers

Thatcham, UK – 16 January 2023: Broadcast test & measurement innovator PHABRIX has announced the availability of the latest update, V4.8, for its acclaimed Qx and QxL rasterizers.

Utilizing PHABRIX patented technology, this new class of waveform Instrumentation delivers all the fine detail needed for camera shading or image grading while retaining the flexibility of real-time operation and support for the wide range of SDR and HDR SDI and IP video formats for which PHABRIX is famous.

The new release utilizes a technique patented by PHABRIX to efficiently deliver a high-resolution image processing pipeline with support for deep color sources up to 12-bits.

With V4.8, users can access a choice of Overlay, Stacked and Parade display modes, each provided with the option of multi-colored, highlighted, green or monochrome traces. The flexibility to display YCbCR, RGB, YRGB, YGRB and individual components is retained along with connected instrument cursor linked to Picture and Data View, and user markers linked to Vectorscope. For detailed inspection, Single Line Mode and H and V magnification are also available.

Luminance Nits scales and operation user-controlled Nits markers are provided for SDR, HLG, PQ, S-Log3 and SR-live HDR formats, and Rec 709 and Rec 2020 colorimetry is supported over the wide-range of YCbCr:422, RGB:444, SDI, 2110, SD*/HD/2K/UHD/4K/EUHD formats for which PHABRIX is renowned.

The Qx Series of rasterizers is available in two platforms, the Qx and QxL, both with a common look and feel, providing an accessible user interface and intuitive toolsets for full operational flexibility and easy migration from an SDI to an IP centric operation. The flexible architecture offers in-field license upgrades for SDI-UHD/4K, 2110-UHD/4K 48-60p RGB (EUHD), PCAP, HDR, AV test signal generation as well as engineering grade data view and ANC packet inspection tools. A factory fitted hardware option provides RTE™ realtime SDI eye and jitter analysis with the further option of a highly advanced SDI-STRESS toolset.

Phillip Adams, CEO of PHABRIX, comments: “We are delighted to be able to add powerful new Waveform Monitoring capabilities to our Qx and QxL rasterizers, and imminently to our new QxP portable waveform monitor. With an increasing number of our customers now working in both SDR and HDR, the need to be able to view all the precise detail required for camera shading, image grading and critical QC has become even more acute. Thanks to the latest update, they will now have easy access to the highly accurate reproduction of image fine detail whilst working across a full range of environments and formats.”

###

About PHABRIX
PHABRIX is a world leader in broadcast test and measurement, with a full range of portable and rackmount systems for rapid fault diagnosis, compliance monitoring, and product development. Technology strengths include IP video stream generation and analysis, advanced HDR/WCG visualization, and ultra-responsive physical layer analysis. The product portfolio includes the top-of-the range Qx Series for hybrid IP, 4K/UHD, and HDR/WCG signal generation, analysis, and video/audio monitoring. The advanced, rackmount Rx range provides fast intermittent fault diagnosis in 3G/HD/SD-SDI environments, using video capture and remote access. For applications demanding ultra-portable instruments, the company also offers the award-winning Sx range. PHABRIX maintains its headquarters and manufacturing facilities in the UK. PHABRIX is a member of the Leader Electronics Corporation group of companies. www.phabrix.com
